Xiaomi Band 3 User Manual Guide

Xiaomi Band 3 User Manual

Installing the Fitness Tracker

1. Insert one end of the fitness tracker into the slot from the front of the wristband.

2. Press down on the other end with your thumb to push the fitness tracker into the slot completely

Wearing the Xiaomi Band

Tighten the wristband around your wrist until there is enough slack to fit about one finger, then adjust the fit until you find a comfortable position. Note: Wearing the band too loosely may impact data collection by the heart rate monitor.

Pairing the Xiaomi Band with a Smartphone

1. To download the Mi Fit app, scan the QR code below or search for "Mi Fit" on the Mi App Store or Apple Store.

2. Open the Mi Fit app, log in to your account and select "Device Pairing", then follow the pairing instructions to proceed. When the Xiaomi Band starts to vibrate and the Bluetooth pairing notification appears on the screen, press the button to complete the pairing process. Note: Please make sure Bluetooth connection is activated on your mobile phone. During the pairing process, please keep the Xiaomi Band near your mobile phone.

Using the Fitness Tracker

After the Xiaomi Band is paired successfully, it will begin to track and analyze your daily activities and sleeping habits. Touch to light up the screen.

Slide up or down on the screen to browse your activity data, measure your heart rate, and access many other features.

Slide left or right on the screen to switch the display between different items.

Removing the Fitness Tracker

Remove the wristband from your wrist, hold on to each end and pull on the wristband until you see a small gap between the fitness tracker and the wristband. Use your finger to pop the fitness tracker out of its slot from the front side of the wristband.

Charging the Xiaomi Band

Please charge your Xiaomi Band immediately when the low power indicator is on.

Important Safeguards

When using the Xiaomi Band to measure your heart rate, please keep your wrist steady.

Xiaomi Band 3 has a water resistance rating of 5ATM. It can be worn in the shower, swimming pool, or while swimming near the shore. It cannot be used, however, while sitting in a sauna or diving in the ocean.

Underwater operation is not supported for the Xiaomi Band's touch-button and touchscreen. After the Xiaomi Band has come in contact with water, please use a soft cloth to wipe away excess water from its surface before using the device.

During daily use, please do not wear the Band too tightly around your wrist and keep its contact area dry. You should also clean the wristband regularly with water. Please stop using the product immediately and seek medical assistance if the contact area on your skin begins to show signs of redness or swelling.

Xiaomi Band 3 Specifications

Name: Xiaomi Band 3

Model: XMSH05HM

Weight of the Fitness Tracker: 8.5 g

Dimensions of the Fitness Tracker: 17.9 x 46.9 x 12 mm

Wristband material: Thermoplastic elastomer

Clasp material: Aluminum alloy

Adjustable length: 155 - 216 mm

Compatible with: Android 4.4/iOS 9.0 or later

Ba­ery capacity: 110mAh

Battery type: Li-Ion polymer battery

Input voltage: DC 5 V

Input current: 250 mA (Max)

Frequency: 2402-2480MHz

Max output: 0dBm

IP rating: 5ATM

Operating temperature: -10°C ~ 50°C

Wireless connectivity: Bluetooth 4.2 BLE
