F/H Error Code WHIRLPOOL Duet Duet HT [WHIRLPOOL]

F/H Error Code WHIRLPOOL Duet Duet HT

F/H Error Code WHIRLPOOL Duet Duet HT. No water detected entering machine or Pressure switch trip not detected

Subject: WHIRLPOOL - Sub Subject: Duet & Duet HT
Date: 4/10/2019 Status: ACTIVE

Viewed

12 times.

ANSWERS Write an Answer

❝F/H Error Code WHIRLPOOL Duet Duet HT❞ answers. technician asked first. Total 4 replies.

technician - 4/10/2019 3:45:11 PM

Failure Code: F/H
Condition: No water detected entering machine or Pressure switch trip not detected.
If after 30 seconds the control does not detect water entering machine and then valves will be turned off and the error code will be displayed.
If the control has turned the water valves on and after 8 minutes the flow meter has detected 10.5 gallons of water passing through it, but has not detected the pressure switch trip, the valves will be turned off and the error code will flash.

Check/Repair:
Press PAUSE/CANCEL twice to clear the display.

1- If there is no water in the unit:
a) Make sure that both valves at the water source(s) are turned on all the way.
b) Check for plugged or kinked inlet hoses or plugged screens in the inlet valves
c) Check inlet valve operation

2- If there is water in the unit:
a) Check Drain pump operation
b) Pressure Switch Hose is in good condition and properly connected to Tub and Pressure switch

3- Check there is not a siphon problem

4- Check wire harness connections to:Inlet Valves, Pressure Switch, Drain Pump, Flow Meter, and Central Control Unit (CCU)

5- Check all hoses for possible leaks

6- Check pressure switch operation

7- Check flow meter operation

8- Check CCU operation

Did you find this helpful? like icon

Askme - 2/29/2020 4:45:30 AM

The manufacturer has assigned this error or fault code to indicate that there is a problem with the amount of water entering the machine. This error code will be displayed if the machine is trying to fill with water but the flow meter doesn’t sense any flow for 30 seconds. In this case, check the water supply to be sure you have good pressure for both hot and cold water. Then, consider replacing the flow meter. This code can also display if the machine is filling with water, the flow meter measures 10.5 gallons of water into the machine, but the water level pressure switch does not turn off the water inlet valves. If this happens the water inlet valve or the water level pressure switch may be defective. Finally, if all other things check out, the problem might be with the central control unit circuit board (CCU) or the wiring to any of these components.
The manufacturer has assigned this error or fault code to indicate that there is a problem with the amount of water entering the machine. This error code will be displayed if the machine is trying to fill with water but the flow meter doesn’t sense any flow for 30 seconds. In this case, check the water supply to be sure you have good pressure for both hot and cold water. Then, consider replacing the flow meter. This code can also display if the machine is filling with water, the flow meter measures 10.5 gallons of water into the machine, but the water level pressure switch does not turn off the water inlet valves. If this happens the water inlet valve or the water level pressure switch may be defective. Finally, if all other things check out, the problem might be with the central control unit circuit board (CCU) or the wiring to any of these components.

Whirlpool F/H - FH No Water Entering Machine or Pressure Switch Failure.

WHIRLPOOL / Duet & Duet HT The manufacturer has assigned this error or fault code to indicate that there is a problem with the amount of water entering the machine.
