How do I find the error code on my Whirlpool Washer?

How do I fix error code f02?

F/02 Failure Code WHIRLPOOL Duet Duet HT

WHIRLPOOL/Duet & Duet HTHow to Fix a Whirlpool Washer With the Code F2?

Whirlpool Duet Washer F05 Error Code

WHIRLPOOL/Duet & Duet HTThe F05 error happens when the water is heated during the wash cycle and the NTC/Temp Sensor is out of range so the computer shuts down the machine and reports the F05 error.

How to Fix F06 on a Whirlpool Duet?

Error Code: F/06 WHIRLPOOL Duet Duet HT F/06 Failure Code

WHIRLPOOL/Duet & Duet HTThe "F06" fault code indicates a drive motor tachometer error. This means the control is unable to properly detect motor speed and the machine will shut down. If the failure occurs during high-speed spin, the door will unlock after 3 minutes.

Whirlpool Duet Washer F07 Error Code

WHIRLPOOL/Duet & Duet HTThe Whirlpool Duet Washer F07 Error is Motor Control Unit (MCU) Error. ... The only thing you can do is try and reset the control by unplugging the washer or killing power to it at the breaker for a minute and restore power. If the F07 error persists after that then the motor control unit / MCU will need to be replaced.

Whirlpool Duet Washer Error Code E01 F09

WHIRLPOOL / Duet & Duet HT Whirlpool Duet Washer Error Code E01 F09 means LONG DRAIN TIME. When your Whirlpool washer goes into drain mode and the drain time is past 8 minutes and not reaching the reset level in the pressure sensor then the valves in the drain are turned off and the drain pump will cease to pump out the water.

F10 Failure Code WHIRLPOOL Duet Duet HT

WHIRLPOOL / Duet & Duet HT If the thermal protector on the MCU heat sink gets too hot, it will open the thermal protector on the heat sink which will stop motor functions and an F10 will be displayed.

How do I fix the f11 code on my Whirlpool Duet washer?

WHIRLPOOL / Duet & Duet HT Resolution: Error code F11 = Serial Communication Error. Error codes can be caused by a Power Surge or other electrical anomaly,attempt to return the washer to operation by following the Hard Reset procedure below. In some cases the control can be non-functioning or may not accept activation from the control panel.

What does f13 error code on a Whirlpool washing machine?

WHIRLPOOL / Duet & Duet HT An F13 error on Hotpoint or Indesit washer dryers indicates a dryer sensor problem. The design of this sensor has been changed, this is how to replace it and resolve the problem.

How do I fix the f14 code on my Whirlpool Duet washer?

WHIRLPOOL / Duet & Duet HT The "F14" fault code implies the Central Control Unit (CCU) was not able to receive data from the on board EEPROM. A power glitch may cause this error. If unplugging the unit for a few minutes and then reapplying power does not resolve the issue; replace the Central Control Unit (CCU).

Whirlpool Duet Washer F15 Error Troubleshooting and Repair

WHIRLPOOL / Duet & Duet HT TheWhirlpool Duet Washer F15 Erroris a Motor Control UnitError. If the central control unit (CCU) detects multiple failures or resets of the motor control unit (MCU) the control will shut down the cycle and report theF15 error. Thiserroris almost always caused by a failed motor control unit.

How to fix Sud Failure Code WHIRLPOOL Duet?

WHIRLPOOL / Duet & Duet HT Excess suds in the washing machine. Washer cannot spin out the water with the excess suds or bubbles. The washer will extend the rinse cycle time to remove the excess detergent SUDS. The washer stops tumbling and puts in water for additional rinsing. The washer pauses or STOPS to allow the bubbles in the suds to be removed.

How to Fix a DL or F Error on a Whirlpool Duet Washer?

WHIRLPOOL / Duet & Duet HT The F/dL code indicates a door lock error on the machine. When the door fails to lock to allow the cycle to begin, it attempts to lock itself at least six times before the error appears on the digital display screen. When the door fails to lock, the machine won't run at all.

What does PF mean on Whirlpool washer?

WHIRLPOOL / Calypso Washing Machine Common solutions for: Whirlpool PF - Power Failure. Not a fault - Indication that power was lost to dishwasher. The manufacturer has assigned this error or fault code to indicate that power was interrupted to the washing machine during a cycle.

F/dU Failure Code, WHIRLPOOL Duet Duet HT

WHIRLPOOL / Duet & Duet HT A Door Unlock Error occurs if the door cannot be unlocked. It will try to unlock the door 6 times before displaying the error.

What does FL mean on a Whirlpool washer?

WHIRLPOOL / Calypso Washing Machine The FL error indicates a flood error. When the FL error is displayed the drain pump should also be running. You didn't mention if the drain pump is running or humming while the FL error is displayed. The most likely cause of the washer not draining is a bad drain pump.

Error Code: Er, WHIRLPOOL Calypso Washing Machine

WHIRLPOOL / Calypso Washing Machine This error code is displayed if the control failed to save cycle information during a power failure. This does not generate an error code beep.

How do I fix the LF on my washing machine?

WHIRLPOOL / Calypso Washing Machine This error code is displayed if the control failed to save cycle information during a power failure. This does not generate an error code beep. Press STOP/CANCEL to clear the display. If the water fill time exceeds ten (10) minutes, the water valves are turned off and “LF” is flashed.

What Does a CE Code Mean on a Whirlpool Calypso Washing?

WHIRLPOOL / Calypso Washing Machine A “CE" error code on a Whirlpool Calypso washing machine indicates a "communications error.” This shows a fault preventing one or more components from reporting normal operating parameters to the machine controller. When this happens, the CE light flashes, the unit beeps once and the motor stops.

What does Ld mean on a Whirlpool washing machine?



WHIRLPOOL / Calypso Washing Machine A Whirlpool washer that displays an "LD" error is indicating that there is an issue with "long draining." This means that the washer is taking too long to drain the water from the drum. The most logical reason for this is a malfunction in the pump.

WHIRLPOOL Calypso Washing Machine Error CA or Cl



WHIRLPOOL / Calypso Washing Machine CA Cl Average current limit Or Instantaneous current limit If a status signal comes back from the motor controller that a current limit has been breached, the unit will return to standby mode and display either CA for average current limit trip or Cl for instantaneous current limit trip.

What Does a CE Code Mean on a Whirlpool Calypso Washing?



WHIRLPOOL / Calypso Washing Machine A “CE" error code on a Whirlpool Calypso washing machine indicates a "communications error.” This shows a fault preventing one or more components from reporting normal operating parameters to the machine controller. When this happens, the CE light flashes, the unit beeps once and the motor stops.

What is SR error in Whirlpool washing machine?

WHIRLPOOL / Calypso Washing Machine “Sr” signifies a failure of the relay in the closed position. With this failure, power to the motor controller cannot be turned off by the machine controller. The machine control board may have a bad relay and may need to be replaced.

What does LS mean on a Whirlpool washer?



WHIRLPOOL / Calypso Washing Machine LS Lid Switch Error The control should flash this error code if it cannot detect the lid switch opening and closing properly. This error code may also be used if there is a disagreement between the motor and machine controllers on the stat if the lid switch.
